VOLTAGE Fuente de alimentación conmutada 12V 1A 12W para CCTV, conector de barril 5,5mm/2,1mm, negra

The VOLTAGE VEA12010 is a high-quality switching mode power supply (SMPS) designed for CCTV cameras, LED strips, routers, and other small electronic devices. With a compact wall-mount design, it delivers a stable 12V DC output at 1A (12W) and features a standard 5.5mm/2.1mm barrel plug with center positive polarity. This adapter is built with multiple protection circuits including over-voltage, over-current, and short-circuit protection, ensuring safe and reliable operation.

Advantages

This power supply offers efficient energy conversion with Level VI efficiency standards, reducing energy waste and heat generation. Its universal input voltage range (100-240V AC) makes it suitable for worldwide use. The included 1-meter output cable provides flexibility in placement, and the EU Type C/F input plug is compatible with Schuko sockets.

Suitable for

• CCTV cameras and surveillance systems
• LED strip lighting
• Routers and networking equipment
• Small electronic devices requiring 12V DC power

Key specifications

• Brand: VOLTAGE
• Model: VEA12010
• Input: 100-240V AC, 50/60Hz
• Output: 12V DC, 1A, 12W
• Connector: 5.5mm outer diameter / 2.1mm inner diameter barrel plug, center positive
• Protection: Over-voltage, over-current, short-circuit
• Efficiency: Level VI
• Certifications: CE, RoHS
• Operating temperature: 0°C to 40°C
• Output cable length: approx. 1 meter

Recommendations

For optimal performance, ensure the connected device does not exceed 12W total power consumption. This adapter is not suitable for outdoor use unless housed in a weatherproof enclosure. Always verify polarity before connection.
