VOLTCRAFT VSPP-1815 Fuente de alimentación de laboratorio para rack, 0-150 V/DC, 0-30 A, 1800 W, programable, USB/RS-485/LAN VC-18673200

In industrial automation and laboratory environments, engineers need a reliable, high-power DC source that can be precisely controlled and remotely operated. The VOLTCRAFT VSPP-1815 is a 19-inch rack-mount laboratory power supply delivering up to 1800 W with an adjustable output of 0-150 V/DC and 0-30 A. It offers USB, RS-485, and LAN interfaces for programming and remote control, making it suitable for automated test systems, burn-in testing, and research applications.

Key specifications

• Output voltage: 0 - 150 V/DC
• Output current: 0 - 30 A
• Output power: 1800 W
• Number of outputs: 1
• Input voltage: 200 - 240 V/AC
• Control interfaces: USB, RS-485, LAN
• Mounting: 19-inch rack, 2U
• Display: LCD
• Protection: OVP, OCP, OPP, OTP
• Cooling: Fan

Why choose it

The VSPP-1815 combines high power density with versatile remote control options, allowing integration into automated test setups. Its rack-mount design saves bench space, and the built-in protections ensure safe operation under demanding conditions.

Ideal use cases

• Automated production testing
• Laboratory research and development
• Burn-in and stress testing of components
• Industrial process control

Good to know

The unit operates from 200-240 V/AC and is fan-cooled. It includes overvoltage, overcurrent, overpower, and overtemperature protection. The LCD display provides clear readouts of voltage and current.
