Wirewin PKW-PIMF-KAT6A cable de red 50 m gris Cat6a S/FTP (S-STP) PKW-PIMF-KAT6 50.0

The Wirewin PKW-PIMF-KAT6A is a 50-metre installation cable built for 10-Gigabit Ethernet over copper. Unlike patch leads that come pre-terminated, this reel gives installers the freedom to cut to exact length and terminate on site, while the S/FTP construction keeps alien crosstalk under control in dense cable runs.

Highlights

• Cat6a performance up to 500 MHz bandwidth
• S/FTP shielding: foil around each pair plus tinned copper braid overall
• Solid 23 AWG copper conductors for stable long-distance runs
• Grey LSZH-free jacket suitable for indoor installation

In daily use

The cable arrives unterminated on a 50 m reel, ready for structured cabling projects where exact lengths matter. Each of the four pairs is wrapped in aluminium foil (PIMF), and the whole bundle is protected by a tinned copper braid. That double shielding is what allows 10GBASE-T to run the full 100 m channel length without signal degradation, even when many cables share a conduit.

Full specifications

• Cable type: Network installation cable, Cat6a
• Shielding: S/FTP (S-STP), pair foil + overall braid
• Length: 50 m
• Colour: Grey
• Data transfer rate: 10 Gigabit Ethernet (10GBASE-T)
• Bandwidth: 500 MHz
• Conductor: Solid copper, 23 AWG, 4 pairs
• Connector ends: Unterminated
• Application: Indoor
• Standards: TIA/EIA-568-C.2, ISO/IEC 11801

Final note

For installers who need a dependable Cat6a backbone cable without the waste of pre-cut lengths, the PKW-PIMF-KAT6A delivers certified performance on a convenient reel.
