Wirewin WCAB PS2 600X600X4U B FP armario rack de pared 4U negro

For installations where floor space is scarce but equipment protection cannot be compromised, the SLIM WIREWIN WCAB PS2 600X600X4U B FP delivers a secure, wall-mounted 4U enclosure with a lockable glass front door and a welded steel frame. Unlike open-frame brackets, this cabinet fully encloses your patch panels, switches, or small servers while keeping them accessible and organized.

Highlights

• 4U wall-mount rack cabinet with 600 x 600 mm footprint
• Lockable glass front door with key lock for security
• Welded steel frame with removable side panels for easy access
• Pre-punched knockouts on top and bottom for cable entry
• Passive ventilation via perforated top and bottom panels
• EIA-310-D compliant 19-inch mounting rails
• Load capacity up to 60 kg
• Includes 2 keys and mounting hardware

In daily use

Mount the cabinet at a convenient height to keep active equipment off desks and away from dust. The glass door allows visual monitoring of indicator lights without unlocking, while the removable side panels simplify cable routing and maintenance. With a usable depth of approximately 550 mm, it accommodates standard 19-inch devices up to 4U tall, making it ideal for small network closets, offices, or industrial control points.

Full specifications

• Rack units: 4U
• External dimensions (W x D x H): 600 x 600 x 250 mm
• Material: Steel
• Colour: Black
• Mounting type: Wall-mounted
• Front door: Lockable glass door
• Side panels: Removable
• Load capacity: 60 kg
• Cable entry: Top and bottom pre-punched knockouts
• Ventilation: Passive (perforated top/bottom)
• IP rating: IP20
• Rack standard: EIA-310-D compliant
• Construction: Welded frame
• Usable depth: Approx. 550 mm
• Included accessories: 2 keys, mounting hardware

Final note

Compact, secure, and built to last, the WCAB PS2 600X600X4U B FP is a practical choice for any wall-mount rack requirement.
