Zebra Sensor de temperatura - para Zebra M-300P

Monitor environmental conditions with laboratory-grade precision using the Zebra TT-30-0006 external temperature probe. Its NTC thermistor sensor delivers ±0.5°C accuracy and 0.1°C resolution across a -20°C to +80°C measurement range, ensuring your Zebra M-300P mobile printer operates within optimal thermal parameters for consistent label quality in demanding field environments.

Overview

Engineered specifically for the Zebra M-300P mobile printer, this external temperature probe provides real-time thermal data to help optimize print performance, prevent overheating, and extend the life of your printing equipment. The 304 stainless steel probe head offers rugged durability, while the 1.5-meter cable allows flexible placement in various mounting configurations.

What stands out

• High-precision NTC thermistor with ±0.5°C accuracy for reliable environmental monitoring
• IP67-rated probe head withstands dust and temporary immersion, ideal for industrial use
• Fast response time under 10 seconds in air for near-instantaneous temperature feedback
• Proprietary Zebra accessory port ensures seamless integration with the M-300P printer
• Wide operating temperature range from -30°C to +100°C for the probe head
• CE and RoHS compliant, meeting international safety and environmental standards

Technical details

• Brand: Zebra
• Model: TT-30-0006
• Product Type: External Temperature Probe
• Sensor Element: NTC Thermistor
• Measurement Range: -20°C to +80°C (-4°F to +176°F)
• Accuracy: ±0.5°C (at 25°C)
• Resolution: 0.1°C
• Connector Type: Proprietary Zebra Accessory Port
• Cable Length: 1.5 meters (approx. 4.9 ft)
• Probe Material: 304 Stainless Steel
• Probe Dimensions (Diameter x Length): 5 mm x 50 mm (0.2 in x 2 in)
• Response Time: < 10 seconds (in air)
• Ingress Protection (Probe Head): IP67
• Operating Temperature (Probe): -30°C to +100°C (-22°F to +212°F)
• Operating Temperature (Cable/Connector): -10°C to +70°C (14°F to +158°F)
• Power Source: Powered by host device (Zebra M-300P)
• Mounting: Integrated clip or screw-mount option
• Units of Measurement: Celsius, Fahrenheit (software selectable)
• Certifications: CE, RoHS Compliant

Our verdict

The Zebra TT-30-0006 temperature probe is an essential accessory for any M-300P mobile printer user who needs to maintain consistent print quality in variable environments. Its rugged construction, precise sensing, and easy integration make it a valuable tool for field service, logistics, and manufacturing applications.
