Adaptador HT Instruments 402-IECN de conector macho banana a conector hembra banana, 4 mm, CAT III 1000 V, 32 A, negro 1003000

Rated for CAT III 1000 V and 32 A, this 4 mm banana plug to banana socket adapter provides a secure, high-voltage connection for professional test and measurement applications.

Overview

The HT Instruments 402-IECN is a single black adapter that converts a 4 mm banana plug to a 4 mm banana socket. It is engineered for safe use in CAT III environments up to 1000 V, making it suitable for industrial and laboratory testing where reliable, high-voltage connections are essential.

What stands out

• CAT III 1000 V safety rating for high-energy circuits
• Robust 32 A current rating for demanding measurements
• Nickel-plated brass contacts ensure low contact resistance and long-term durability
• Insulated polyamide body provides excellent mechanical and electrical protection
• Plug-in connection for quick and secure attachment

Technical details

• Connector type: 4 mm banana plug to 4 mm banana socket
• Measurement category: CAT III
• Voltage rating: 1000 V
• Current rating: 32 A
• Contact material: Brass, nickel-plated
• Insulation material: Polyamide (PA)
• Operating temperature range: -20 to +50 °C
• Safety standard: IEC 61010-031

Our verdict

A dependable, high-spec adapter for professionals who need safe and reliable connections in high-voltage test setups.
