ALLNET ALL-BRICK-0060 Switch Gigabit Smart Managed de 8 puertos con 2 ranuras SFP

The ALLNET ALL-BRICK-0060 is a high-performance 8-port Gigabit Smart Managed Layer 2 switch, designed for small to medium-sized businesses seeking reliable and efficient network connectivity. With 8 Gigabit Ethernet ports and 2 SFP slots, this switch delivers a switching capacity of 20 Gbps and a forwarding rate of 14.88 Mpps, ensuring smooth data transfer for bandwidth-intensive applications. Its fanless design guarantees silent operation, making it ideal for noise-sensitive environments like offices or meeting rooms.

Advantages

This switch offers advanced management features including VLAN support, QoS, IGMP snooping, and link aggregation, providing granular control over network traffic. The web-based GUI, CLI, and SNMP management interfaces simplify configuration and monitoring. Security features such as port security, DoS defense, and storm control protect your network from threats. The compact desktop and rack-mountable design (1U) allows flexible installation.

Suitable for

• Small to medium-sized businesses requiring a managed network
• Office environments where silent operation is essential
• Deployments needing VLAN segmentation and traffic prioritization
• Networks with mixed copper and fiber connections via SFP slots

Key specifications

• 8 x 10/100/1000 Mbps Ethernet ports
• 2 x 1000 Mbps SFP slots
• Switching capacity: 20 Gbps
• Forwarding rate: 14.88 Mpps
• MAC address table: 8K entries
• Jumbo frame support: up to 9KB
• Management: Web GUI, CLI (Telnet/SSH), SNMP v1/v2c/v3
• VLAN: 802.1Q tag-based, port-based
• QoS: 802.1p, DSCP
• Spanning Tree: STP/RSTP/MSTP
• Link Aggregation: LACP, static trunk
• IGMP Snooping: v1/v2/v3
• Security: Port security, DoS defense, storm control
• Fanless design for silent operation
• Power: Internal AC 100-240V, 50/60Hz
• Mounting: Desktop, 1U rack-mountable

Recommendations

For optimal performance, use high-quality Cat5e or Cat6 Ethernet cables. The switch supports jumbo frames, which can improve throughput for large file transfers. Configure VLANs to segment traffic and enhance security. Enable QoS to prioritize critical applications like VoIP or video conferencing.
