ALLNET NetworkOptix ALL-NX305 mini-PC-NVR Intel Core i3-N305 16GB RAM 256GB SSD Win11 Pro

Unlike conventional NVRs that bind you to closed ecosystems, the ALLNET ALL-NX305 pairs a fanless 8-core Intel Core i3-N305 with dual 2.5G Ethernet and Windows 11 Pro, giving you the freedom to run NetworkOptix VMS as a standard application. This rugged aluminum mini PC delivers silent, dust-resistant 24/7 operation, making it ideal for control rooms, retail back offices, and industrial sites.

Highlights

• 8-core Intel Core i3-N305 CPU with up to 3.8 GHz boost for smooth multi-stream recording and playback
• 16 GB LPDDR5 memory and 256 GB NVMe SSD for responsive system operation and ample local storage
• Dual 2.5 Gigabit Ethernet ports for high-bandwidth camera networks and isolated management VLANs
• Fanless aluminum enclosure ensures silent, dust-resistant 24/7 operation
• Pre-installed Windows 11 Pro and ready for NetworkOptix VMS deployment
• Versatile connectivity: Wi-Fi 6, Bluetooth 5.2, HDMI 2.0, DisplayPort 1.4, and multiple USB ports

In daily use

Deploy the ALL-NX305 in control rooms, retail back offices, or industrial sites where reliability and low noise are critical. Its fanless design eliminates moving parts, reducing maintenance and allowing installation in dusty or sensitive environments. The dual 2.5G LAN ports enable camera traffic segmentation and failover, while the powerful i3-N305 processor handles multiple high-resolution streams with ease. With VESA mount support, the unit can be hidden behind a monitor or mounted on a wall, saving valuable desk space.

Full specifications

• Processor: Intel Core i3-N305 (8 cores, 8 threads, up to 3.8 GHz)
• Memory: 16 GB LPDDR5 (onboard)
• Storage: 256 GB NVMe SSD (M.2 2280)
• Operating system: Windows 11 Pro
• Graphics: Intel UHD Graphics
• Ethernet: 2x 2.5 Gigabit Ethernet (RJ45)
• Wireless: Wi-Fi 6 (802.11ax), Bluetooth 5.2
• Video outputs: 1x HDMI 2.0, 1x DisplayPort 1.4
• USB ports: 2x USB 3.2 Gen 2 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x USB 2.0 Type-A
• Audio: 1x 3.5mm headphone/mic combo jack
• Cooling: Fanless
• Chassis: Aluminum alloy
• VESA mount: Yes
• Power supply: External DC 12V/3A adapter

Final note

The ALLNET ALL-NX305 redefines video surveillance recording by combining open software flexibility with robust, silent hardware built for continuous operation.
