BACHMANN BN ESSENTIAL PDU con medición 24xC13, 6xCEE7/3 3,0m CEE 16/5p

The BACHMANN BN ESSENTIAL Metered PDU is a professional-grade 19-inch rackmount power distribution unit designed for data centers and server rooms. It provides 24 IEC C13 and 6 Schuko CEE7/3 outlets with a 3.0-meter CEE 16A 5-pin input cable, enabling reliable 3-phase power distribution. The integrated metering display allows real-time monitoring of current, voltage, power, and energy consumption.

Advantages

Real-time power monitoring via integrated LED display helps optimize load balancing and prevent overloads. The 1U form factor saves valuable rack space, while the anodized aluminum housing ensures durability and heat dissipation. Three 16A circuit breakers provide individual phase overload protection.

Suitable for

• Data centers requiring 3-phase power distribution
• Server racks with mixed IEC C13 and Schuko equipment
• IT environments needing accurate power metering

Key specifications

• PDU Type: Metered PDU
• Mounting: 19-inch Rackmount, 1U
• Input: CEE 16A 5-pin (IEC 60309), 400V AC 3-phase, 16A
• Output: 24x IEC C13 + 6x Schuko CEE7/3
• Cable Length: 3.0 m
• Metering: Current (A), Voltage (V), Active Power (kW), Apparent Power (kVA), Energy (kWh), Power Factor, Frequency (Hz)
• Display: Integrated 3-digit 7-segment LED
• Overload Protection: 3x 16A Circuit Breakers
• Max Power: 11 kW
• Housing: Anodized Aluminum, Black
• Operating Temperature: 0 - 45 °C
• Protection Class: IP20
• Frequency: 50/60 Hz
• Certifications: CE, RoHS, WEEE

Recommendations

Ideal for IT professionals requiring precise power monitoring and reliable distribution in 19-inch racks. Ensure your facility has a compatible CEE 16A 5-pin outlet.
