BCS BCS-UTP-KVM-1080P Extensor KVM HDMI sobre Cat5e/Cat6, 60m, 1080p, negro

The BCS BCS-UTP-KVM-1080P is a high-performance HDMI KVM extender that transmits video, audio, and USB signals up to 60 meters over a single Cat5e or Cat6 UTP cable. Designed for professional AV installations, it supports 1080p resolution and provides near-zero latency for real-time control. The kit includes a sender and receiver unit, two power adapters, and a USB cable, making it a complete plug-and-play solution for extending your workstation or media setup.

Advantages

Extend your HDMI and USB signals up to 60m without signal degradation. The metal alloy housing ensures durability and effective heat dissipation. With HDCP and EDID support, compatibility with a wide range of sources and displays is guaranteed. The integrated USB 2.0 hub allows connection of keyboard and mouse for remote KVM control.

Suitable for

• Extending a computer setup to a remote monitor and peripherals in offices, control rooms, or digital signage
• Home theater or gaming setups where the source is located far from the display
• Educational or corporate environments requiring centralized equipment with remote access

Key specifications

• Max Resolution: 1080p (1920x1080)
• Max Transmission Distance: 60 meters
• Cable Type: Cat5e/Cat6 UTP
• Video Input (Sender): 1x HDMI Type-A
• Video Output (Receiver): 1x HDMI Type-A
• KVM Input (Sender): 1x USB Type-B
• KVM Outputs (Receiver): 2x USB Type-A
• HDMI Version: 1.3
• USB Version: 2.0
• HDCP Support: Yes
• EDID Support: Yes
• Power Supply: DC 5V/1A (2x included)
• Latency: Near Zero
• Housing Material: Metal Alloy
• Plug and Play: Yes
• Audio Support: Yes (via HDMI)
• Indicator Lights: Power, Link LEDs
• Operating Temperature: 0°C to 60°C
• Kit Contents: 1x Sender, 1x Receiver, 2x Power Adapters, 1x USB-A to USB-B Cable
• Colour: Black

Recommendations

For optimal performance, use high-quality Cat6 cables and keep the total cable length within 60 meters. This extender is ideal for extending a single computer to a remote monitor and USB peripherals. Ensure both sender and receiver are powered with the included adapters.
