Transceptor CBO E1MG-100FX-A Fibra óptica 100 Mbit/s 1310 nm

Fiber optic transceiver CBO E1MG-100FX-A Fiber Optic 100Mbps 1310nm is a compact single-wavelength module designed for 100 Mbps data transmission over optical fiber at 1310 nm. It connects network devices with fiber interfaces to create reliable point-to-point links suitable for local area networks, CCTV systems and industrial network applications. The small form factor allows straightforward integration into existing fiber infrastructures and simplifies replacement or expansion of fiber segments.

Advantages

This transceiver supports stable 100 Mbps full-duplex data transfer over single-mode fiber using a 1310 nm wavelength, ensuring consistent signal quality over typical metropolitan and campus distances. The compact module design offers easy installation into compatible fiber ports or media converters, reducing deployment time. Built for interoperability with standard fiber networking equipment, it provides predictable performance for Ethernet-based systems used in surveillance, automation and enterprise networking.

Suitable for

• Point-to-point Ethernet links between switches and routers
• Fiber backbone connections for LAN and campus networks
• CCTV and video surveillance systems requiring fiber transport
• Industrial Ethernet and automation networks with fiber segments

Key specifications

• Data rate: 100 Mbps
• Wavelength: 1310 nm
• Fiber type: single-mode fiber (SMF)
• Transmission mode: single-wavelength, full-duplex
• Form factor: compact fiber transceiver module
• Typical application range: metropolitan and campus distances (dependent on fiber quality and link budget)

How to use

Install the transceiver into a compatible fiber port or media converter according to the host device documentation, then connect single-mode fiber cable using appropriate connectors. Verify link indicators on both ends of the fiber link and confirm network settings on connected devices to match 100 Mbps operation. When replacing an existing module, power down the host equipment if recommended by the manufacturer, insert the transceiver securely, and restore power before testing the link.

Recommendations

Ensure fiber connectors are clean and undamaged before installation to maintain optimal signal quality. Use single-mode fiber and matching connector types for 1310 nm operation, and perform link testing after installation to verify attenuation and continuity. Store spare modules in anti-static packaging and avoid mechanical stress on fiber runs to prolong service life.
