BlueOptics Ubiquiti UACC-OFC-MA-MPMP-50M Cable de conexión MPO-MPO Multimodo OM4 50 metros

Engineered for high-density 40GbE and 100GbE links, this 50-meter MPO-12 OM4 patch cable delivers a low 0.35 dB insertion loss and a return loss of ≥20 dB, ensuring signal integrity across data center interconnects. The aqua LSZH jacket and Type B polarity make it a reliable choice for modern fiber infrastructures.

Overview

The BlueOptics UACC-OFC-MA-MPMP-50M is a premium multi-mode fiber optic patch cable featuring MPO male connectors on both ends. With 12 fibers in an OM4 core, it supports wavelengths of 850 nm and 1300 nm, enabling high-speed data transmission up to 100 Gbps. The cable is 50 meters long, ideal for backbone connections or longer runs within a facility.

What stands out

• High-performance OM4 multi-mode fiber with 50 µm core and 125 µm cladding
• MPO-12 male connectors with Type B polarity for easy integration
• Low insertion loss of ≤0.35 dB and return loss of ≥20 dB
• Durable LSZH jacket in aqua, halogen-free for safety
• Supports 10GbE, 40GbE, and 100GbE applications
• Compliant with TIA/EIA-568-C.3 and IEC 60793-2-10 Type A1a.3

Technical details

• Cable type: Fiber optic patch cable
• Fiber mode: Multi-mode
• Fiber class: OM4
• Connector A: MPO male
• Connector B: MPO male
• Cable length: 50 m
• Number of fibers: 12
• Jacket color: Aqua
• Core diameter: 50 µm
• Cladding diameter: 125 µm
• Wavelength support: 850 nm / 1300 nm
• Data rate support: 10GbE, 40GbE, 100GbE
• Polarity: Type B
• Insertion loss: ≤0.35 dB
• Return loss: ≥20 dB
• Jacket material: LSZH
• Application: Data center interconnects, high-density networking
• Standards compliance: TIA/EIA-568-C.3, IEC 60793-2-10 Type A1a.3
• Operating temperature: -20°C to 70°C

Our verdict

For professionals needing a long-reach, high-density fiber solution, this BlueOptics MPO cable offers exceptional performance and reliability. Its OM4 rating and low loss characteristics make it a solid investment for future-proofing your network.
