Cable SAS FUJITSU PY-CBS079, conexión externa/interna, longitud 96 cm + 12 cm

SAS cable FUJITSU PY-CBS079, external/internal connection, length 96 cm + 12 cm is a purpose-built short link for connecting SAS storage devices and controllers. The cable features two joined segments — a longer 96 cm section for external routing and a shorter 12 cm segment intended for internal chassis or module connections. It is designed to match FUJITSU server and storage rack layouts where a compact, manufacturer-compatible SAS connection is required for direct data links between controllers and drives.

Advantages

The FUJITSU PY-CBS079 cable provides a compact combined external/internal solution that reduces cable clutter while maintaining standard SAS signal paths. Its two-segment design lets installers route the longer section externally while keeping the short segment inside the chassis for secure module attachment. The cable is intended for straightforward replacement or addition of a direct SAS connection in enterprise hardware, minimizing compatibility issues when used with FUJITSU equipment and compatible SAS controllers.

Suitable for

• Connecting SAS controllers to external storage enclosures in server racks
• Replacing or extending short SAS links inside server chassis
• Compact installations requiring one external and one internal cable segment

Key specifications

• Connection type: SAS (Serial Attached SCSI) external/internal combined cable
• Segments: two joined cable segments — 96 cm and 12 cm lengths
• Application: direct data connection between SAS controllers and storage devices
• Intended use environment: server and storage rack installations

How to use

Install the longer 96 cm segment to route between the external port on a server or controller and the storage enclosure routing path required in the rack. Position the shorter 12 cm segment inside the chassis or module to connect directly to drive backplanes or internal SAS ports. Ensure connectors are aligned and fully seated before powering devices. Follow server and storage vendor procedures for hot-swap or maintenance operations if applicable.

Recommendations

Use the FUJITSU PY-CBS079 cable in environments where a compact external-to-internal SAS link is needed; avoid sharp bends and excessive strain on both segments. Verify compatibility with the server or storage controller manufacturer guidance and confirm secure seating of connectors to maintain reliable SAS signal transmission.
