Caja de cuadro eléctrico DIN PULSAR ARADIN2 2 módulos 35mm Gris ABS IP20

The PULSAR ARADIN2 is a compact and robust DIN rail housing designed for mounting electronic modules, relays, and power supplies on standard TH35 DIN rails. With a 2-module width (35mm) and made from grey ABS plastic (RAL 7035), it offers reliable protection and easy installation in industrial and commercial indoor environments.

Advantages

• Compact 2-module design saves space on the DIN rail.
• Durable ABS plastic with UL94-V0 flammability rating ensures safety.
• Ventilation slots allow heat dissipation for reliable operation.
• Removable cover simplifies access and maintenance.
• Lightweight and easy to install.

Suitable for

• Housing for DIN rail mount electronic modules
• Relay and timer enclosures
• Power supply and controller housings
• Industrial automation and control cabinets

Key specifications

• Mounting: DIN Rail TH35
• Number of Modules: 2 (35mm width)
• Material: ABS Plastic
• Colour: Grey (RAL 7035)
• Protection Rating: IP20
• Operating Temperature: -10°C to +40°C
• Flammability Rating: UL94-V0
• Internal Dimensions (approx.): 31 x 86 x 50 mm (W x H x D)
• Ventilation: Yes (slots)
• Cover: Removable/Openable
• Certifications: CE, RoHS

Recommendations

For optimal performance, ensure the DIN rail is clean and properly grounded. Use appropriate end brackets to secure the housing. This product is intended for indoor use only.
