Caja empotrable JUNG CD 1520 WW, Caja de conexión empotrable para tomas de corriente tipo F, blanca

JUNG CD 1520 WW is a white flush-mounted outlet junction box designed to house Type F power sockets. Intended for concealed wiring in residential and commercial interiors, the box provides a recessed mounting cavity that secures the socket mechanism and guides incoming cables. The neutral white colour integrates with standard wall finishes while offering a robust, fixed enclosure for safe electrical installation.

Advantages

The outlet box is made for compatibility with Type F sockets, offering precise dimensions and a stable mounting surface that reduces movement of the socket mechanism after installation. Its flush-mounted design enables low-profile installations and preserves wall aesthetics. The enclosure provides defined cable entry points to facilitate neat wiring and reliable grounding connections. White finish simplifies matching with common cover plates and wall colours.

Suitable for

Key specifications

How to use

Prepare the wall recess to fit the junction box following local installation standards and the dimensions of the Type F socket mechanism. Insert the CD 1520 WW into the prepared flush cavity, align it accurately, and secure it according to mounting instructions and local electrical codes. Route supply cables through the provided entry points, connect conductors to the socket terminals, and ensure proper earthing. After testing electrical connections, attach the socket mechanism and the final cover plate to complete the installation.

Recommendations

Installations should be performed by a qualified electrician in accordance with local regulations. Verify compatibility with the chosen Type F socket mechanism and confirm that the wall cavity and mounting method provide sufficient support. Use appropriate insulation and strain relief for incoming cables to maintain long-term safety and performance.
