Campana de pared CATA RENOVA PURE AIR MNV90 GWH acero inoxidable recirculación

The CATA RENOVA PURE AIR MNV90 GWH is a wall-mounted extractor hood in stainless steel designed for recirculating installation. It provides LED lighting and an aluminium/charcoal grease filter, and is intended to be installed at minimum distances of 55 cm from electric hobs and 65 cm from gas hobs. The unit operates on 220–240 V, 50 Hz, with a motor power of 158 W and features a top exhaust location and an A+ energy efficiency class.

Advantages

The extractor offers six extraction speeds including a turbo/booster function for rapid air removal, an electronic control panel with a digital display and remote control for convenient operation, and true connectivity for integration with compatible systems. LED lighting improves visibility over the cooking area while stainless steel construction supports durability and easy cleaning. The recirculating mode with aluminium and charcoal filters allows installation where external ducting is not available.

Suitable for

• Domestic kitchens requiring wall-mounted recirculating extraction
• Installations where external venting is not possible
• Homes needing compact extraction with LED lighting and remote control

Key specifications

• Type: Wall-mounted extractor hood
• Model: CATA RENOVA PURE AIR MNV90 GWH
• Finish: Stainless steel
• Extraction type: Recirculating (aluminium/charcoal filter)
• Motor power: 158 W
• Supply: 220–240 V, 50 Hz
• Speeds: 6 extraction levels + 1 turbo/booster
• Lighting: LED
• Controls: Electronic panel with digital display and remote control
• Energy class: A+
• Exhaust location: Top
• Minimum installation distances: 55 cm from electric hobs, 65 cm from gas hobs

How to use

Install the wall-mounted extractor at the recommended minimum distance above the cooktop and connect to the household supply (220–240 V, 50 Hz). For recirculating operation fit the aluminium and charcoal filters according to the installation instructions. Use the electronic panel or supplied remote control to select one of six speeds or activate the turbo mode for intensive extraction. Switch on the LED lights to illuminate the cooking surface as needed.

Recommendations

Regularly clean or replace the aluminium grease filter and replace the charcoal filter according to the manufacturer's intervals to maintain performance. Use the turbo function only for short periods to avoid excessive energy use, and ensure the unit is installed at the specified minimum distances from hobs for safe operation.
