Carcasa NVMe FANTEC NVMe-X2U32-20G Estación de clonación Dual-PCIe a USB 3.2

FANTEC NVMe-X2U32-20G is an NVMe enclosure and dual-drive clone station that connects two M.2 PCIe NVMe modules to a host via USB 3.2. The unit provides a compact external housing for two NVMe modules and a direct disk-to-disk cloning function without a PC. It is designed for technicians and advanced users who need portable NVMe access, fast file transfers, backups, and straightforward drive servicing.

Advantages

The device combines a dual M.2 NVMe enclosure with a stand-alone cloning feature, enabling direct duplication between two NVMe modules without additional software. USB 3.2 interface delivers high transfer throughput for data migration and backup tasks. The enclosure supports hot-swapping of drives and preserves the NVMe form factor performance while offering the convenience of external connection and maintenance operations.

Suitable for

• Direct disk-to-disk cloning of M.2 NVMe drives
• Data migration between NVMe modules
• External access to NVMe drives for backups and file transfers
• Drive testing, diagnostics and servicing by IT technicians

Key specifications

• Interface to host: USB 3.2 Gen 2x2 (up to 20 Gbps)
• Drive bays: two M.2 NVMe (PCIe) module slots
• Cloning: hardware disk-to-disk cloning without PC required
• Form factor supported: M.2 single-sided and double-sided modules (NVMe)
• Power: external power supply for stable operation during cloning and high-load transfers

How to use

Install each M.2 NVMe module into the corresponding slot following the device’s mechanical guide and secure them. Connect the external power supply, then connect the enclosure to a host using a USB 3.2 cable to access the drives as external storage. For standalone cloning, follow the unit’s cloning procedure: select source and target, start the cloning process and monitor status indicators; the device performs a direct sector-level copy without requiring a computer during the operation.

Recommendations

Use high-quality USB 3.2 cables and connect to compatible USB 3.2 Gen 2x2 ports to achieve maximum throughput. Ensure target drive capacity is equal to or greater than the source when performing cloning. Operate the enclosure on a stable surface with adequate ventilation and connect the provided external power during cloning or extended transfers to prevent interruptions.
