Conector macho de aparato C13 Bachmann 915.173 Negro

The Bachmann 915.173 C13 power plug in black is a thermoplastic mains connector for cable mounting. It is rated for AC input voltage up to 250 V and a maximum current of 10 A, with an earthing contact and right-hand cable exit. The design includes a screw terminal, kink protection and strain relief for cables up to 3G 1.00 mm², providing a secure electrical connection for a range of electronic devices.

Advantages

The thermoplastic housing with integrated earthing contact offers a compact and durable solution for mains connections. Screw terminals simplify installation and maintenance, while the built-in kink protection and strain relief reduce mechanical stress on the cable and contacts. The right-hand cable exit enables flexible cable routing in installations.

Suitable for

• Powering desktop computers, monitors and peripherals with a C13 inlet
• Professional AV and studio equipment requiring a compact C13 connector
• Replacement or repair of existing mains leads with compatible cable size (3G 1.00 mm²)

Key specifications

• Model: Bachmann 915.173 (C13)
• Color: Black
• Rated voltage: 250 V AC
• Rated current: 10 A
• Cable capacity: up to 3G 1.00 mm²
• Housing material: thermoplastic
• Termination: screw terminal
• Cable exit: right-hand

How to use

Strip the cable to the length recommended by the connector manufacturer, insert conductors into the screw terminals and tighten securely to the specified torque. Ensure the earth conductor is connected to the earthing contact. Route the cable through the built-in kink protection and strain relief, then close the housing according to the assembly instructions to secure the cable and contacts.

Recommendations

Use only cables of the specified type and cross-section (up to 3G 1.00 mm²) and ensure the connector’s current and voltage ratings (10 A, 250 V AC) are not exceeded. Perform installation with the power disconnected and, if required, by qualified personnel to ensure proper earthing and safe operation.
