Conector RJ45 Cat.6A METZ CONNECT montaje en campo, apantallado, sin herramientas, pack de 10

This METZ CONNECT RJ45 plug stands out with its tool-free field termination, allowing fast and reliable assembly without special tools. The die-cast zinc housing provides robust shielding for industrial and data center environments.

Highlights

• Cat.6A performance for 10 Gigabit Ethernet
• Shielded design with die-cast zinc housing
• Tool-free termination for solid and stranded wires
• Supports PoE, PoE+, and 4PPoE
• 10 pieces per pack

In daily use

The plug accepts solid wires from AWG 24/1 to AWG 22/1 and stranded wires from AWG 27/7 to AWG 22/7, with cable outer diameters from 5.0 mm to 9.0 mm. Gold-plated contacts ensure reliable connections over at least 750 mating cycles.

Full specifications

• Connector type: RJ45 plug, 8P8C
• Performance category: Cat.6A (ISO/IEC 11801, EN 50173)
• Shielding: Shielded (STP/FTP)
• Termination: Field terminable, tool-free
• Transmission speed: 10 Gigabit Ethernet (10GBase-T)
• PoE compatibility: PoE, PoE+, 4PPoE (IEEE 802.3at/af/bt)
• Wire gauge (solid): AWG 24/1 - AWG 22/1
• Wire gauge (stranded): AWG 27/7 - AWG 22/7
• Cable outer diameter: 5.0 mm - 9.0 mm
• Housing material: Die-cast zinc
• Contact plating: Gold-plated
• Operating temperature: -40 °C to +70 °C
• Mating cycles: ≥ 750
• Colour: Silver (housing)
• Pack quantity: 10 pieces

Final note

This 10-pack is ideal for installers and IT professionals who need reliable, high-performance RJ45 connections on site.
