Conversor de medios LevelOne RJ45 a SC Fast Ethernet, fibra multimodo, 2 km, PoE PD

LevelOne’s FVT-0103TXFC is new Power-over-Ethernet-converters that transfer data from 10/100BaseTX copper to fiber interfaces. These PoE Converters are designed to receive data and power from PoE networks and then to refer data out through fiber connections thus eliminating extra power cables to extend the usefulness of the network.

LevelOne’s PoE converter complies with IEEE802.3af standard. The10/100 Base-TX port auto-senses 10 or 100Mbps connection speeds, auto-negotiates half-/full-duplex modes, and auto-selects MDI-X media type. FVT-0103TXFC with high-quality Multi-mode SC optical fiber connector port, this converter will give your PoE network the ability to interface with fiber connections over a distance of up to 2km.

With its compact design, our PoE converter easily fit on any limited space. No software is required. You can easily active this device by simply connecting it to the network cable and it’s ready to go.

- 10/100BASE-TX UTP to 100BASE-FX fiber media conversion
- Multi-mode transmission over fiber, up to 2 km
- High-quality SC optical fiber connector port
- Complies with IEEE 802.3af PoE standard as a PD device
- Over-current protection and under-current detection
- DIP Switch for customized configurations

LevelOne RJ45 to SC Fast Ethernet Media Converter, Multi-Mode Fiber, 2km, PoE PD. Maximum data transfer rate: 100 Mbit/s, Converter input interface: 10Base-T, 100Base-TX, Converter output interface: 100Base-FX. Fiber mode structure: Multi-mode, Fiber cable diameters supported (core/cladding): 50/125,62.5/125,100/140 µm. LED indicators: FDX, Activity, Link, PoE, Power, Product colour: Black. Fiber optic connector: SC, Connectivity technology: Wired. Output current (48V): 0.06 A
