Convertidor de tensión MEAN WELL DDR-15G-5

The MEAN WELL DDR-15G-5 is an ultra-slim DC-DC DIN-rail voltage converter providing a steady 5V output in a compact industrial form factor. With dimensions of 17.5 mm (W) x 54.5 mm (D) x 90 mm (H), this converter is designed for stable voltage regulation and efficient energy conversion in control cabinets and automation systems where panel space is limited.

Advantages

The DDR-15G-5 offers a compact design that eases installation on standard DIN rails and minimizes space usage. It delivers a consistent 5V output suitable for sensitive electronics and control modules, while its industrial construction supports reliable operation in typical electrical installations. The product’s slim profile and measurable dimensions enable straightforward integration into existing setups without extensive cabinet modifications.

Suitable for

• Powering 5V control electronics and sensors in industrial automation
• Embedded systems and communication modules requiring stable 5V supply
• Control cabinets and distribution panels with limited space

Key specifications

• Brand: MEAN WELL
• Model: DDR-15G-5 (MPN: DDR-15G-5)
• Output voltage: 5 V
• Dimensions: 17.5 mm (W) x 54.5 mm (D) x 90 mm (H)
• Form factor: Ultra slim DIN-rail DC-DC converter
• EAN: 4021087050906

How to use

Mount the DDR-15G-5 on a standard 35 mm DIN rail inside a suitable enclosure. Connect the input supply and load according to the wiring diagram provided by the manufacturer, observing polarity and terminal torque recommendations. After wiring, apply input power and verify the 5V output with a multimeter before connecting sensitive equipment. Follow standard electrical safety procedures during installation and maintenance.

Recommendations

Install the converter in a well-ventilated panel area away from heat sources. Verify compatibility with your system’s input voltage range and ensure proper fusing on the input side to protect against overloads.
