CPU para servidor Intel Xeon E-2414, 4 núcleos, 2,6 GHz base, 4,5 GHz boost, 12 MB caché, LGA 1700, 55 W, DDR5 ECC, PCIe 5.0

The Intel Xeon E-2414 is a server-grade processor operating at a base frequency of 2.6 GHz with a 12 MB cache. Built on the Raptor Lake design and using the LGA 1700 socket, this CPU targets entry to mid-level server and workstation deployments. It supports dual-channel DDR5 memory up to 128 GB, offers PCIe Gen 5 connectivity options, and includes Intel Turbo Boost Technology 2.0 to increase frequencies up to 4.5 GHz when workload conditions allow. The processor includes four physical cores and does not provide integrated graphics, focusing on compute and I/O performance for enterprise workloads.

Advantages

The processor combines stable base frequency and Turbo Boost capability to handle variable server loads while conserving power under light usage. Support for DDR5 memory and PCIe Gen 5 improves data throughput and reduces latency for modern server components. The LGA 1700 socket compatibility simplifies upgrades in systems designed around current Intel platforms. The compact 12 MB cache and four-core layout deliver predictable performance for single-threaded and multi-threaded server tasks.

Suitable for

• Small to medium business servers
• Edge computing and compact rack servers
• File, print and domain controllers
• Virtualization hosts with modest VM density
• Compute nodes for light database and application servers

Key specifications

• Base frequency: 2.6 GHz
• Maximum Turbo frequency: up to 4.5 GHz (Intel Turbo Boost Technology 2.0)
• Cores: 4 physical cores
• Cache: 12 MB
• Socket: LGA 1700
• Memory support: Dual-channel DDR5, up to 128 GB
• PCIe: Gen 5 support
• Integrated graphics: Not available

How to use

Install the Intel Xeon E-2414 into a compatible LGA 1700 motherboard following the motherboard manufacturer’s installation procedure, apply an appropriate thermal solution, and ensure BIOS/firmware support for the processor and DDR5 memory. Configure memory modules in the recommended dual-channel arrangement and verify BIOS settings for Turbo Boost and power management to match your workload profile. Use supported server operating systems and keep chipset drivers and firmware up to date to ensure stability and performance.

Recommendations

For reliable operation in server environments, pair the processor with ECC-capable DDR5 memory and a motherboard that provides robust VRM cooling. Set BIOS power profiles according to required performance versus energy efficiency, and monitor temperatures under peak load. When deploying virtualization or database services, size memory and storage I/O to match the expected workload rather than relying solely on CPU frequency.
