Cubierta protectora contra la lluvia para wallbox Eiffel Basic, impermeable para la familia Pulsar — cubierta protectora para estaciones de carga exterior

Rain Cover for Eiffel Basic for Pulsar family by Wallbox is a waterproof protective cover designed for outdoor installation on Pulsar series chargers. It shields the charging unit from rain and moisture, supporting reliable operation in wet conditions and contributing to longer equipment service life. The cover is compatible with Eiffel Basic pedestals and intended for use with Wallbox Pulsar family chargers.

Advantages

The cover offers IP-level protection suitable for outdoor exposure and an IK10 impact resistance rating. It is lightweight (net weight 1.1 kg) and compact, with a durable construction that tolerates storage temperatures from -40 °C to 70 °C. The product is easy to mount on compatible Eiffel Basic pedestals and carries a 24-month warranty.

Suitable for

• Protecting Wallbox Pulsar family chargers from rain and moisture
• Outdoor home charging stations
• Light commercial or semi-public charging points installed on Eiffel Basic pedestals

Key specifications

• Producer product name: Rain Cover for Eiffel Basic for Pulsar family
• Brand: Wallbox
• MPN: COVER-EIFBS-PLP1
• EAN: 8436575278230
• Net weight: 1.1 kg
• Gross weight: 1.2 kg; tare weight: 0.10 kg
• Dimensions (package): gross width 330 mm × gross depth 220 mm × gross height 128 mm; product height 322.2 mm × width 216 mm
• Packing quantity: 1 pc
• Materials (packaging): paper/pasteboard 80 g; plastic (no PET) 20 g
• Volume (package): 0.0092928 m³
• Embedded battery: No; WEEE tax: No
• Environmental/technical: Storage temperature -40 °C to 70 °C; Protection rating IK10
• Warranty: 24 months

How to use

Install the rain cover onto an Eiffel Basic pedestal according to the pedestal and charger mounting instructions. Ensure the Pulsar family charger is properly mounted and all electrical connections are completed before fitting the cover. Position the cover so it fully shelters the charger from direct rainfall and secures to the pedestal following the supplied fixings or manufacturer guidance.

Recommendations

Use the rain cover only with compatible Wallbox Pulsar family chargers and Eiffel Basic pedestals. Regularly inspect the cover and mounting points for damage, especially after severe weather or impacts, and clean with a mild detergent and water. Do not modify the cover or obstruct ventilation openings of the charger when fitted.
