EATON DILM150-XHI11 bloque de contacto auxiliar, 1NO+1NC, montaje frontal, para contactores DILM150-DILM500 277946

Contactors often need additional signaling or control contacts, and the EATON DILM150-XHI11 auxiliary contact block solves this by adding one normally open and one normally closed contact to compatible contactors. It mounts directly on the front of EATON DILM150 to DILM500 contactors, expanding control possibilities without extra wiring complexity.

Who is it for

This auxiliary contact block is for panel builders, machine OEMs, and maintenance technicians who use EATON DILM150–DILM500 contactors and need extra auxiliary contacts for interlocks, status indication, or control logic.

Main features

• 1 normally open (NO) and 1 normally closed (NC) contact
• Front mounting on EATON DILM150 to DILM500 contactors
• Rated operational current up to 6 A at 230 V AC (AC-15)
• Screw terminals for secure wiring
• Silver alloy contacts for long electrical life

Specifications

• Product type: Auxiliary contact block
• Mounting: Front mounting
• Compatibility: EATON DILM150 to DILM500 contactors
• Contacts: 1 NO + 1 NC
• Rated operational current (AC-15): 6 A (230 V), 4 A (400 V)
• Rated operational current (DC-13): 10 A (24 V), 3 A (110 V)
• Rated operational voltage: up to 690 V AC, 220 V DC
• Rated insulation voltage (Ui): 690 V AC
• Rated impulse withstand voltage (Uimp): 6 kV
• Degree of protection: IP20 (terminals)
• Terminal type: Screw terminals
• Contact material: Silver alloy
• Electrical durability: 1.3 x 10^6 operations (AC-15)
• Mechanical durability: 10 x 10^6 operations
• Ambient operating temperature: -25 to +60 °C

Tips

Verify that your contactor is within the DILM150–DILM500 range before ordering. The block clips onto the front of the contactor without tools, but ensure the contactor is de-energized during installation.
