Eaton DILM7-10 contactor de potencia 24 V DC, tripolar, 1 contacto auxiliar NO, 7 A AC-3, 3 kW, bornes de tornillo 276565

Industrial electricians and panel builders use the Eaton DILM7-10 power contactor to switch three-phase motors and resistive loads in control cabinets and machine installations. This contactor has a 24 V DC coil, three main normally open contacts, and one built-in auxiliary normally open contact for control feedback or interlocking.

Key specifications

• Coil voltage: 24 V DC
• Main contacts: 3 NO (normally open)
• Auxiliary contacts: 1 NO (normally open)
• Rated operational current AC-3 (400 V): 7 A
• Rated operational power AC-3 (400 V): 3 kW
• Rated operational current AC-1 (400 V): 22 A
• Rated insulation voltage: 690 V
• Rated impulse withstand voltage: 6 kV
• Number of poles: 3
• Connection: screw terminals
• Mounting: DIN rail or screw mounting
• Degree of protection: IP20 (terminals)
• Mechanical durability: 10 million operations
• Electrical durability (AC-3): 1.5 million operations
• Ambient operating temperature: -25 to +60 °C

Why choose it

The DILM7-10 is a compact contactor in frame size S00, making it suitable for space-constrained installations. Its screw terminals provide secure, vibration-resistant connections. The built-in auxiliary contact reduces the need for additional add-on blocks, simplifying wiring and saving panel space.

Ideal use cases

• Switching small three-phase motors up to 3 kW at 400 V
• Controlling resistive heating loads up to 22 A
• Integration into PLC-based control systems with 24 V DC outputs
• Replacement for older DILM series contactors in existing installations

Good to know

The contactor complies with IEC/EN 60947 standards for low-voltage switchgear and controlgear. It is designed for reliable switching in industrial environments and can be mounted on standard 35 mm DIN rail or with screws.
