EFB-Elektronik Conector de poste 16-Pin Header gris 2,54mm Pitch recto macho

The EFB-Elektronik Pfostenverbinder 16-Pin Header is a high-quality male pin header connector designed for reliable PCB connections. With a 2.54mm pitch and straight orientation, this connector is ideal for a wide range of electronic applications. The grey PBT insulator ensures durability and the gold flash over nickel plating on brass contacts provides excellent conductivity and corrosion resistance.

Advantages

This pin header offers a robust and secure connection for 16-pin configurations. The 2.54mm pitch is standard for many prototyping and production boards. The straight design simplifies PCB layout and soldering. RoHS compliance ensures environmental safety.

Suitable for

• PCB prototyping and development boards
• Industrial control systems
• Automation equipment
• Electronic devices requiring reliable pin connections

Key specifications

• Connector Type: Pin Header
• Number of Pins: 16 (2x8)
• Pin Pitch: 2.54 mm
• Orientation: Straight
• Gender: Male
• Mounting Type: Through-Hole
• Insulator Color: Grey
• Insulator Material: PBT
• Flammability Rating: UL94 V-0
• Contact Material: Brass
• Contact Plating: Gold Flash over Nickel
• Current Rating: 3 A per contact
• Voltage Rating: 250 V AC/DC
• Operating Temperature: -40°C to +105°C
• Termination Style: Solder
• RoHS Compliant: Yes

Recommendations

For best results, use with matching female socket connectors. Ensure proper soldering techniques for reliable connections. Suitable for both commercial and industrial environments.
