EFB-Elektronik Tira de pines 20-Pin, 2,54 mm de paso, 2x10, recto, gris, E-WP 5461

The EFB-Elektronik 20020.3 is a high-quality 20-pin pin header connector designed for reliable PCB connections. With a 2.54 mm pitch and 2x10 configuration, this straight male connector is ideal for various electronic applications. The grey PBT insulator ensures durability and UL 94V-0 flammability rating for safety.

Advantages

This connector offers secure through-hole mounting, tin-plated brass contacts for excellent conductivity, and a wide operating temperature range from -40°C to +105°C. RoHS compliant, it meets environmental standards.

Suitable for

• PCB board connections
• Industrial electronics
• Prototyping and development
• Automation systems

Key specifications

• Connector Type: Pin Header
• Number of Pins: 20
• Pin Pitch: 2.54 mm
• Number of Rows: 2
• Pin Configuration: 2x10
• Contact Gender: Male
• Orientation: Straight
• Color: Grey
• Mounting Type: Through-Hole
• Insulator Material: PBT
• Contact Material: Brass
• Contact Plating: Tin
• Current Rating: 3 A per pin
• Voltage Rating: 250 V AC/DC
• Operating Temperature: -40°C to +105°C
• Flammability Rating: UL 94V-0
• Product Series: E-WP
• Compliance: RoHS

Recommendations

For optimal performance, ensure proper soldering and avoid exceeding rated current. Suitable for use in controlled environments.
