EFB Elektronik fibra pigtail LC 62.5/125 OM1 azul 2m

The EFB Elektronik Fiber Pigtail LC 62.5/125 OM1 Blue 2m is a high-quality fiber optic pigtail designed for reliable splicing in patch panels, ODFs, and distribution boxes. It features a simplex LC connector with PC polish, ensuring low insertion loss and high return loss for optimal signal transmission.

Advantages

This pigtail offers excellent performance with typical insertion loss ≤0.3 dB and return loss ≥20 dB. The LSZH jacket provides safety in case of fire, and the tight buffer design ensures durability. It is RoHS compliant and supports operating wavelengths of 850 nm and 1300 nm.

Suitable for

• Splicing in fiber optic patch panels
• Optical distribution frames (ODFs)
• Distribution boxes and termination points
• Multimode OM1 network installations

Key specifications

• Connector: LC simplex, PC polished
• Fiber: Multimode OM1, 62.5/125 µm
• Length: 2 meters
• Jacket color: Blue
• Jacket material: LSZH
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +85°C
• Mating cycles: ≥ 500

Recommendations

For best results, use with compatible LC adapters and ensure proper splicing techniques. Ideal for indoor network infrastructure.
