EFB Elektronik INFRALAN I-B(ZN)BH 12G 50/125µm OM4 LSZH Erika Violet CPR-B2CA

The EFB Elektronik INFRALAN I-B(ZN)BH 12G 50/125µm OM4 LSZH Erika Violet CPR-B2CA is a high-performance fibre optic patch cable designed for demanding 12G SDI and high-speed data transmission applications. This cable features a 50/125µm OM4 multimode fibre core, ensuring excellent bandwidth and distance capabilities. The LSZH (Low Smoke Zero Halogen) jacket provides enhanced safety in confined spaces, while the CPR-B2CA classification confirms compliance with European fire safety standards. The distinctive erika violet colour aids in easy identification and cable management.

Advantages

This cable offers superior signal integrity and low insertion loss, making it ideal for broadcast, medical, and data centre environments. The OM4 fibre supports high data rates over longer distances compared to OM3, and the LSZH jacket reduces toxic smoke emission in case of fire. The CPR-B2CA rating ensures it meets strict building regulation requirements for fire performance.

Suitable for

• Broadcast and professional video (12G-SDI)
• Data centre interconnects
• High-speed networking (10/40/100 Gigabit Ethernet)
• Medical imaging and AV systems
• Any installation requiring low smoke and halogen-free cabling

Key specifications

• Fibre type: OM4 multimode 50/125µm
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Colour: Erika violet
• Fire rating: CPR-B2CA
• Connector type: LC (typical for this series, verify variant)
• Insertion loss: ≤0.3 dB (typical)
• Return loss: ≥20 dB (typical)
• Operating temperature: -20°C to +70°C

Recommendations

For optimal performance, ensure proper handling and avoid sharp bends. Use with compatible 12G-SDI or high-speed network equipment. Store in a clean, dry environment when not in use.
