EFB Elektronik Pigtail de fibra E2000/APC8° OS2, set de 12 colores, 2m

The EFB Elektronik Fiber Pigtail E2000/APC8° OS2 12-Color Set is a high-quality, pre-terminated fiber optic pigtail set designed for single-mode applications. Each set includes 12 pigtails, each 2 meters long, with E2000/APC connectors polished to an 8° angle for optimal return loss performance. The pigtails are color-coded according to DIN VDE 0888 for easy identification and organization.

Advantages

This pigtail set offers low insertion loss (≤0.3 dB) and high return loss (≥60 dB), ensuring reliable signal transmission. The LSZH jacket material provides safety in enclosed spaces, and the 0.9 mm tight buffer design allows for easy handling and splicing. The 12-color set simplifies fiber identification and management in data centers, FTTH, and telecommunications networks.

Suitable for

• Data center fiber optic cabling
• FTTH (Fiber to the Home) installations
• Telecommunications networks
• LAN (Local Area Network) fiber infrastructure

Key specifications

• Product Type: Fiber Optic Pigtail Set
• Connector Type: E2000/APC
• Fiber Type: OS2 Single-mode
• Number of Fibers: 12
• Length per Pigtail: 2 m
• Polishing Type: APC (Angled Physical Contact)
• Angle of Polish: 8°
• Fiber Core/Cladding Diameter: 9/125 µm
• Cable Diameter: 0.9 mm (Tight Buffer)
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Insertion Loss (max.): ≤ 0.3 dB
• Return Loss (min.): ≥ 60 dB
• Color Coding Standard: DIN VDE 0888 (12 standard colors)
• Operating Temperature Range: -20 to +70 °C
• Storage Temperature Range: -40 to +85 °C
• Compliance: RoHS, REACH

Recommendations

For optimal performance, ensure proper cleaning of connectors before mating. Use appropriate splice trays and enclosures for protection.
