EFB Elektronik Pigtail de fibra LC 50/125 µm OM4, Erika Violet, 2 m

The EFB Elektronik Fiber Pigtail LC 50/125 µm OM4 is a high-quality, pre-terminated fiber optic pigtail designed for reliable and efficient network connections. With a length of 2 meters and an LC connector, this pigtail is ideal for splicing to fiber cables in data centers, LANs, and telecommunications applications. The OM4 multimode fiber ensures high bandwidth and performance for 10 GbE and 40/100 GbE networks.

Advantages

This pigtail offers low insertion loss (≤0.3 dB) and high return loss (≥30 dB), ensuring minimal signal degradation. The LSZH jacket provides safety in enclosed spaces, and the Erika violet color allows for easy identification. The 0.9 mm buffer diameter and UPC polish ensure compatibility with standard splice trays and connectors.

Suitable for

• Data centers requiring high-density cabling
• Local Area Networks (LAN) with OM4 infrastructure
• Storage Area Networks (SAN) for high-speed data transfer
• Telecommunications and enterprise networks

Key specifications

• Product Type: Fiber Optic Pigtail
• Fiber Type: Multimode OM4
• Connector: LC (Male)
• Core/Cladding: 50/125 µm
• Length: 2 m
• Jacket Color: Erika Violet
• Jacket Material: LSZH
• Connector Polish: UPC
• Insertion Loss: ≤0.3 dB
• Return Loss: ≥30 dB
• Number of Fibers: 1 (Simplex)
• Buffer Diameter: 0.9 mm
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Minimum Bend Radius: 10 x Outer Diameter
• Compliance: RoHS, REACH

Recommendations

For optimal performance, use with OM4-rated patch panels and splice trays. Ensure proper cleaning of connectors before installation. This pigtail is compatible with standard LC adapters and is suitable for use in structured cabling systems.
