ELEKTRO-PLAST Cuadro de distribución de plástico Elegant NT 24M IP40 350

The ELEKTRO-PLAST Elegant Plastic Distribution Board NT 24M is a high-quality surface-mounted enclosure designed for indoor electrical installations. With 24 modules arranged in 2 rows, it provides ample space for circuit breakers and other DIN rail components. The transparent smoked door allows easy visual inspection while maintaining a sleek appearance.

Advantages

This distribution board offers a robust ABS plastic construction with IP40 protection, making it suitable for dry indoor environments. The included N+PE terminal blocks simplify wiring, and the 180° door opening provides full access for installation and maintenance. The self-extinguishing material and glow wire test compliance ensure safety.

Suitable for

• Residential and commercial electrical distribution
• Surface mounting on walls in dry locations
• Installations requiring up to 24 modules

Key specifications

• Installation Type: Surface-mounted
• Enclosure Material: High-quality ABS Plastic
• Number of Modules: 24 (2x12)
• Ingress Protection (IP) Rating: IP40
• Number of Rows: 2
• Door Type: Transparent (Smoked)
• Color: White (RAL 9003)
• DIN Rail: Included (Standard 35mm)
• Terminal Blocks: N+PE (Neutral and Earth) terminal blocks included
• Glow Wire Test: 650°C
• Impact Resistance: IK07
• Operating Temperature: -5°C to +40°C
• Application Environment: Indoor, dry locations
• Flammability Rating: Self-extinguishing
• Halogen-Free: Yes
• Standards Compliance: EN 60439-3, EN 62208
• Door Opening Angle: 180°
• Mounting: Wall mounting via screws

Recommendations

For optimal performance, use with compatible DIN rail components and ensure proper grounding. Suitable for residential and light commercial applications.
