Eltako Actuador de persiana IP 2 canales montaje en carril DIN 230V AC 3A 30064019

The Eltako Shading Actuator IP is a network-enabled control module for motorized blinds, shutters, and awnings, delivering precise positioning and centralized automation through Ethernet connectivity. Its standout capability is the automatic runtime calibration, which learns travel times for accurate scene recall without manual setup.

Advantages

Two independent potential-free relay channels each handle up to 500 W of motor load, making it suitable for large window coverings. Integrated overload and short-circuit protection safeguard connected drives, while standby loss of only 0.8 W keeps energy consumption minimal. The actuator supports Eltako Building Cloud and Eltako Connect, enabling remote control, scheduling, and scene management from a smartphone or tablet. Local pushbutton inputs allow manual override even when the network is unavailable.

Suitable for

• Automated shading in residential smart homes
• Office buildings with centralized blind control
• Retrofit projects using existing Ethernet infrastructure
• Integration with Eltako Building Cloud for remote access

Key specifications

• 2 independent channels, potential-free relay outputs
• Switching capacity: 230 V AC, 3 A per channel (cos φ = 0.6)
• Maximum motor load: 500 W per channel
• Power supply: 230 V AC, 50 Hz; standby loss 0.8 W
• DIN rail mounting, width 4 TE (72 mm)
• Protection class IP20, operating temperature -20 °C to +50 °C
• Communication via Ethernet, Eltako Building Cloud / Eltako Connect
• Automatic runtime calibration, end position detection, scene control
• Local control via Eltako Connect pushbuttons
• Housing material: plastic

Recommendations

For reliable and future-proof shading automation, pair this actuator with Eltako Connect pushbuttons and integrate it into the Eltako Building Cloud. Ensure proper ventilation in the distribution board and verify that motor inrush currents do not exceed the relay rating.
