EPRADO-R19-18U/600-BLUE Armario rack de pared 18U 19 pulgadas azul 600x600x800mm

The EPRADO-R19-18U/600-BLUE is a high-quality 18U wall mount rack cabinet designed for secure and organized installation of 19-inch network and IT equipment. Constructed from cold rolled steel with a durable blue (RAL 5012) finish, this cabinet offers a robust solution for server rooms, offices, and data centers where space is limited.

Advantages

This wall mount rack cabinet provides excellent protection and organization for your valuable equipment. The tempered glass front door with lock ensures visibility while preventing unauthorized access. Removable, lockable side panels allow easy maintenance and cable management. With a static load capacity of 60 kg, it can accommodate a variety of devices such as switches, patch panels, and small servers.

Suitable for

• Network switches and routers
• Patch panels and cable management
• Small servers and UPS units
• Audio/visual equipment
• IT and telecommunications installations

Key specifications

• Rack Standard: 19-inch
• Rack Units: 18U
• External Dimensions (WxDxH): 600 x 600 x 800 mm
• Usable Internal Depth: Approximately 550 mm
• Material: Cold Rolled Steel
• Colour: Blue (RAL 5012)
• Front Door: Tempered Glass with Lock
• Side Panels: Removable, Lockable
• Mounting Type: Wall-Mountable
• Static Load Capacity: 60 kg
• Cable Entry: Top and Bottom
• Ventilation: Passive (Perforated Top/Bottom)
• Mounting Rails: Adjustable 19" Front and Rear Rails
• Protection Rating: IP20
• Construction: Welded Frame
• Included Accessories: 2 Keys, Wall Mounting Kit
• Compliance: CE, RoHS

Recommendations

For optimal performance, ensure the wall mount rack is securely attached to a solid wall capable of supporting the total weight of the cabinet and installed equipment. Use the included wall mounting kit and follow the installation manual carefully. This cabinet is ideal for environments requiring a compact, secure, and organized rack solution.
