EUROLITE Ambience Control 4 RGBW controlador de pared LED 24V 50531055

The EUROLITE Ambience Control 4 RGBW 24V stands out as a compact, flush-mount wall controller that puts full RGBW colour mixing and dimming at your fingertips without the need for a complex DMX setup. Unlike basic single-colour dimmers or bulky remote-controlled receivers, this unit integrates directly into a standard wall box and drives up to 288 W of 24 V LED strip or modules across four channels, making it a practical choice for residential accent lighting, retail displays, and hospitality spaces where simple, reliable control is key.

Highlights

• 4-channel RGBW output with 24 V DC constant voltage, up to 3 A per channel and 12 A total.
• Intuitive rotary knob and push-button interface for brightness, colour selection, and built-in programs.
• Four static colour presets and four dynamic colour-change programs, plus memory function to recall the last setting after power-off.
• Flush-mount design fits standard wall boxes; screw terminals ensure secure, permanent wiring.
• IP20 rating for indoor use, with a robust plastic housing and operating range from 0 to 40 °C.

In daily use

Installation is straightforward for anyone familiar with low-voltage LED wiring: connect your 24 V DC power supply and RGBW LED strip to the clearly labelled screw terminals, then mount the controller into a standard flush box. The rotary knob lets you smoothly dim from 0 to 100%, while short presses cycle through the four static colours (red, green, blue, white) and long presses access the dynamic programs. The memory function ensures your chosen scene is restored after a power interruption, eliminating the need to reconfigure each time. Because it operates entirely on the low-voltage side, no mains wiring is required at the control point, enhancing safety and simplifying retrofits.

Full specifications

• Product type: LED wall controller
• Control channels: 4 (RGBW)
• Output voltage: 24 V DC
• Max. output current per channel: 3 A
• Max. total output current: 12 A
• Max. total output power: 288 W
• Input voltage: 24 V DC
• Control interface: Rotary knob, push buttons
• Dimming range: 0–100%
• Colour mixing: RGBW
• Pre-programmed programs: 4 static colours, 4 colour change programs
• Memory function: Yes (stores last setting)
• Connection type: Screw terminals
• Mounting type: Flush mount (standard wall box)
• Housing material: Plastic
• Operating temperature range: 0–40 °C
• Protection rating: IP20
• Number of control zones: 1

Final note

For installers and end users seeking a no-fuss RGBW control solution that disappears into the wall, the Ambience Control 4 delivers dependable performance and a clean aesthetic, backed by EUROLITE's reputation for professional lighting components.
