EXSYS EX-11227HMVS hub metálico USB 3.2 Gen 1 de 7 puertos con kit para carril DIN

The EXSYS EX-11227HMVS is a robust 7-port USB 3.2 Gen 1 hub designed for industrial and commercial environments. Featuring a metal housing, DIN-rail mounting capability, and a VIA VL817 chipset, it delivers reliable high-speed data transfer up to 5 Gbps. The hub includes a USB 3.2 Gen 1 Type-A to Type-B cable (1.2m) and a 12V/3A power adapter, supporting a wide input voltage range of 7-24V DC. Each port provides up to 900 mA output current, making it suitable for powering multiple peripherals.

Advantages

Durable metal construction ensures longevity in demanding settings. DIN-rail and wall-mount options offer flexible installation. Wide power input range (7-24V DC) allows integration with various power sources. LED indicators per port provide clear status monitoring.

Suitable for

• Industrial automation and control systems
• Point-of-sale (POS) systems
• Digital signage and kiosks
• Server rooms and IT infrastructure
• Laboratory and testing equipment

Key specifications

• USB Standard: USB 3.2 Gen 1 (compatible with USB 3.0/3.1 Gen 1)
• Number of Downstream Ports: 7 (USB Type-A)
• Upstream Port: USB Type-B
• Max Data Transfer Rate: 5 Gbps
• Chipset: VIA VL817
• Power Input: DC 7-24V (12V/3A adapter included)
• Max Output Current per Port: 900 mA
• Housing Material: Metal
• Mounting: DIN-rail, wall-mount
• LED Indicators: Power, Link/Activity per port
• Operating Temperature: 0°C to 55°C
• Included Cable: USB 3.2 Gen 1 Type-A to Type-B (1.2m)
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, use with USB 3.0 or higher devices. The hub is compatible with Windows, macOS, and Linux operating systems. Ideal for expanding connectivity in workstations, server racks, and industrial panels.
