EXSYS EX-3500 Controladora RAID - 2 conexiones SATA II internas, PCI Express x1, RAID 0/1

RAID controller with two internal SATA II ports for building fast, redundant storage arrays. The EXSYS EX-3500 plugs into a PCI Express x1 slot and supports RAID 0 and RAID 1, delivering up to 300 MB/s per port for responsive data access.

Advantages

Bootable arrays let you run the operating system directly from the RAID volume. The Marvell 88SE6121 chipset ensures reliable performance with Windows and Linux systems.

Suitable for

• Adding hardware RAID to a workstation or server with a free PCIe x1 slot
• Mirroring two SATA drives for real-time data protection
• Striping two drives for faster throughput in media editing or gaming

Key specifications

• Host interface: PCI Express x1
• Internal ports: 2 x SATA II (3 Gb/s)
• RAID levels: 0, 1
• Chipset: Marvell 88SE6121
• Data transfer rate: 300 MB/s per port

Recommendations

For reliable RAID 0/1 with SATA II drives, the EX-3500 offers a straightforward upgrade path in a compact PCIe x1 form factor.
