EXSYS EX-49060 Adaptador USB 3.0 conector hembra de 10 pines a terminal block

For system builders and technicians working inside a PC, the EXSYS EX-49060 provides a convenient internal USB 3.0 Type-A port by connecting to the motherboard's 19-pin header. This short adapter is ideal for adding an internal USB device or creating a service port without routing cables to the outside.

Key specifications

• Connector 1: USB 3.0 19-pin male header
• Connector 2: USB 3.0 Type-A female
• USB standard: USB 3.0 (USB 3.2 Gen 1)
• Data transfer rate: up to 5 Gbps
• Cable length: 0.2 m
• Cable colour: black
• Connector plating: nickel
• Jacket material: PVC
• Plug and play: yes

Why choose it

This adapter leverages the high-speed SuperSpeed USB 3.0 interface to ensure fast data transfers for internal peripherals. Its compact 20 cm length reduces cable clutter inside the case, and the nickel-plated connectors provide reliable contact. The blue Type-A insert clearly identifies it as a USB 3.0 port.

Ideal use cases

• Connecting an internal USB 3.0 device, such as a card reader or front panel hub, to the motherboard header.
• Providing an internal Type-A port for diagnostics or temporary connections.
• Adapting a 19-pin header to a standard Type-A socket for custom builds.

Good to know

The cable is designed for motherboards with a standard 19-pin USB 3.0 header. It is plug-and-play, requiring no additional drivers. The female Type-A connector allows direct connection of any standard USB device internally.
