FIELDMANN FDB 2004-E Fuente de alimentación cerrada 150W 24V DC

Industrial-grade enclosed power supply delivering stable 24 VDC output at 150 W for demanding automation, LED lighting, and control systems. Its fanless convection cooling ensures silent, maintenance-free operation even in dusty environments.

Advantages

High efficiency above 88% reduces energy waste and heat generation. Comprehensive protection against over voltage, over current, short circuit, and over temperature safeguards both the supply and connected equipment. Wide input voltage range (90–264 VAC) allows global use without switches or adjustments.

Suitable for

• Industrial automation and PLC systems
• LED lighting installations and signage
• Security and access control equipment
• Test and measurement instruments
• Telecommunications and networking devices

Key specifications

• Output: 24 VDC, 6.25 A, 150 W
• Input: 90–264 VAC, 47–63 Hz
• Efficiency: >88%
• Cooling: Fanless convection
• Protections: OVP, OCP, SCP, OTP
• Operating temperature: -20°C to +70°C
• MTBF: >100,000 hours
• Certifications: CE, UL, TUV, CB, RoHS
• Connectors: Terminal blocks (input and output)
• Ripple & noise: <150 mVp-p

Recommendations

For reliable 24V DC power in industrial settings, the FIELDMANN FDB 2004-E offers robust construction, wide temperature tolerance, and essential safety certifications. Its compact metal case and terminal block connections simplify installation in control cabinets.
