Finder 07L.55.300 Cable de conexión, 14 polos, 3 m, Gris/Blanco, 230 V AC

The Finder 07L.55.300 stands out as a flat, 14-pole connection cable engineered specifically for interfacing PLC and control systems with Finder MasterINTERFACE relay bases. Unlike generic ribbon cables, its IDC connector ensures a secure, tool-free connection to compatible 39 Series bases, while the open wire ends offer flexibility for custom wiring. The grey PVC jacket and white connector provide clear visual identification in control cabinets.

Highlights

• Flat cable design saves space and simplifies routing in dense panels
• 14-pin IDC connector mates directly with Finder MasterINTERFACE bases
• Open wire ends allow connection to PLC terminals or other devices
• Rated for 230 V AC and 1 A per pole, suitable for low-power signal circuits
• 3-meter length covers typical control cabinet distances

In daily use

Installation is straightforward: plug the IDC connector into the relay base, then terminate the open wires as needed. The flat profile reduces clutter, and the grey/white colour scheme helps distinguish this cable from power wiring. The PVC insulation provides basic mechanical protection, and the cable operates reliably from -20°C to +70°C, covering most industrial environments.

Full specifications

• Product type: Connection cable
• Cable type: Flat cable
• Number of poles: 14
• Rated voltage: 230 V AC
• Rated current per pole: 1 A
• Conductor cross-section: 0.14 mm²
• Conductor material: Copper
• Insulation material: PVC
• Connector 1: 14-pin IDC connector
• Connector 2: Open wire ends
• Colour: Grey cable, white connector
• Operating temperature range: -20°C to +70°C
• Compatibility: Finder MasterINTERFACE relay bases (e.g., 39 Series)
• Mounting type: Plug-in
• Unit quantity: 1 piece

Final note

This cable is a direct replacement for Finder's original accessory, ensuring compatibility and performance in automation projects.
