Finder 48.P8.7.024.4050 Relé de interfaz 24 V DC 2 CO 10 A

Interface relay with 2 changeover contacts, rated 10 A, coil 24 V DC. Offers reliable switching for industrial control systems.

Advantages

Silver nickel contacts ensure long electrical life. Compact plug-in design for 93 series sockets.

Suitable for

• Industrial automation
• Control panel interfacing
• Signal amplification

Key specifications

• Coil voltage: 24 V DC
• Contact configuration: 2 changeover (DPDT)
• Rated current: 10 A
• Contact material: AgNi
• Max switching voltage: 400 V AC / 125 V DC
• Coil power consumption: 0.6 W
• Dielectric strength coil-contact: 6 kV (1.2/50 µs)
• Ambient temperature range: -40 to +70 °C
• Mounting: plug-in for 93 series sockets
• Protection degree: RT I (flux proof)
• Electrical life: 100,000 cycles at rated load
• Mechanical life: 10,000,000 cycles

Recommendations

Use with Finder 93 series sockets for secure mounting and easy wiring.
