Fuente de alimentación MEAN WELL HEP-240-24A, 240 W, salida 24 V, entrada 90–305 V, RoHS, dimensiones 68×244,2×38,8 mm

The MEAN WELL HEP-240-24A is a 240 W single-output industrial AC‑DC power supply that delivers 24 V DC at up to 10 A. It features a wide input voltage range of 90–305 V AC, built-in power factor correction (PFC) and adjustable output via a potentiometer. The unit is housed in a compact metal enclosure (68 × 244.2 × 38.8 mm) designed for installation in control cabinets and equipment racks and meets RoHS requirements.

Advantages

The HEP-240-24A offers stable 24 V output with up to 10 A current capability and an adjustable voltage trim for fine tuning. Its wide 90–305 V AC input range supports global mains compatibility and the integrated PFC improves input power quality. The metal case provides mechanical robustness and the design withstands vibration up to 10 G, making it suitable for industrial environments. RoHS compliance ensures it meets common environmental standards.

Suitable for

• Industrial automation controllers and PLCs
• Industrial electronics and control cabinets
• LED lighting systems and LED drivers
• Machine building and equipment racks

Key specifications

• Output: 24 V DC
• Rated power: 240 W
• Maximum output current: 10 A
• Input voltage range: 90–305 V AC
• Output adjustment: potentiometer (Vo-Io trim)
• Protection/standards: RoHS compliant
• Dimensions: 68 × 244.2 × 38.8 mm
• Vibration resistance: up to 10 G
• Brand/Model: MEAN WELL HEP-240-24A (MPN HEP-240-24A, EAN 4021087032315)

How to use

Mount the power supply inside a suitable control cabinet or equipment rack with adequate ventilation and secure fixing. Connect the AC input to the 90–305 V mains following local wiring regulations and connect the 24 V DC output to the load, observing correct polarity. Use the built-in potentiometer to fine-tune the output voltage if required. Ensure the total connected load does not exceed 240 W or 10 A continuous.

Recommendations

Install the unit where ambient temperature and airflow meet the manufacturer's specifications, provide proper fusing on the input side, and avoid exposure to excessive shock or sustained temperatures above rated limits. For critical applications, verify startup and loading behavior under expected operating conditions.
