Getac F110 Havis DS-GTC-213 Soporte para Vehículo - VESA 75x75 para F110 G5/G6/G7

The Getac F110 Havis DS-GTC-213 Vehicle Cradle is a rugged docking solution designed to securely mount your Getac F110 G5, G6, or G7 rugged tablet in a vehicle. Manufactured by Havis, this heavy-duty cradle features a VESA 75x75 mm mounting pattern and provides a comprehensive set of I/O ports for seamless integration. The front-loading, spring-loaded mechanism with push-button release ensures quick and easy docking, while the keyed lock secures the tablet against theft. Built to withstand harsh environments, it is MIL-STD-810G compliant for shock and vibration resistance and operates in temperatures from -20°C to 60°C.

Advantages

This vehicle cradle offers robust construction with heavy-gauge steel and aluminum, ensuring long-lasting durability. The integrated cable management with strain relief protects connections, and the triple RF pass-through (GPS, WWAN, WLAN) maintains antenna functionality. With multiple USB, Ethernet, serial, and video ports, it transforms your tablet into a full-fledged mobile workstation.

Suitable for

• Getac F110 G5 rugged tablet
• Getac F110 G6 rugged tablet
• Getac F110 G7 rugged tablet
• Vehicle installations requiring VESA 75x75 mounting
• Field service, public safety, and industrial applications

Key specifications

• Product Type: Vehicle Docking Station
• Compatibility: Getac F110 G5, G6, G7
• Mounting Standard: VESA 75 x 75 mm
• Material: Heavy-gauge steel, aluminum
• Power Input: 12-30V DC
• USB Ports: 3x USB 3.0, 1x USB 2.0
• Ethernet: 1x RJ45 Gigabit Ethernet
• Serial: 1x DB9 RS-232
• Video Output: 1x HDMI, 1x VGA
• Audio: 1x Speaker, 1x Microphone
• Security: Keyed lock (two keys included)
• Shock & Vibration: MIL-STD-810G compliant
• Operating Temperature: -20°C to 60°C (-4°F to 140°F)
• Antenna Pass-Through: Triple RF (GPS, WWAN, WLAN)
• Certifications: CE, FCC, E-Mark
• Docking Mechanism: Front-loading, spring-loaded, push-button release
• LED Indicators: Power, Dock Status
• Power Adapter: Not included (requires separate vehicle power adapter)

Recommendations

For a complete vehicle mounting solution, pair this cradle with a compatible vehicle power adapter and a VESA mount. Ensure your Getac F110 tablet is equipped with the necessary connectors for full functionality. This cradle is ideal for professionals who require reliable tablet docking in demanding mobile environments.
