GETFORT 38863 Módulo adaptador de fibra óptica SC dúplex para paneles de parcheo, 6 puertos, 12 fibras, negro

Managing high-density fiber connections in data centers and enterprise networks requires reliable, organized patching. The GETFORT 38863 SC Duplex adapter module solves this by providing six SC duplex ports in a single snap-in unit, supporting up to 12 fibers. It fits standard 1U/2U fiber optic patch panels and enclosures, streamlining cable management and reducing installation time.

Who is it for

Network engineers, data center technicians, and IT professionals who need to terminate and manage fiber optic links in structured cabling systems. Ideal for both multimode and singlemode applications, this module is a versatile choice for backbone and horizontal cabling.

Main features

• Six SC duplex ports, supporting up to 12 fibers for high-density patching.
• Tool-less snap-in mounting for quick installation into compatible patch panels.
• Zirconia ceramic ferrules ensure low insertion loss and high return loss for stable performance.
• Cold-rolled steel housing with black finish for durability and a professional look.
• Supports multimode (OM1-OM4) and singlemode (OS1/OS2) fibers, making it adaptable to various network types.
• Complies with RoHS, IEC 61754-4, and TIA/EIA-568-C.3 standards.

Specifications

• Product Type: Fiber Optic Adapter Module
• Connector Type: SC Duplex
• Number of Ports: 6
• Fiber Capacity: 12 Fibers
• Mounting Mechanism: Tool-less Snap-in
• Adapter Ferrule Material: Zirconia Ceramic
• Module Housing Material: Cold-rolled Steel
• Module Housing Color: Black
• Insertion Loss (Typical): ≤ 0.3 dB
• Return Loss (Typical): ≥ 50 dB (UPC)
• Operating Temperature Range: -20°C to +70°C
• Storage Temperature Range: -40°C to +85°C
• Mating Cycles Durability: > 1000
• Application Environment: Indoor
• Standards Compliance: RoHS, IEC 61754-4, TIA/EIA-568-C.3
• Fiber Mode Support: Multimode (OM1, OM2, OM3, OM4) & Singlemode (OS1, OS2)

Tips

For best results, ensure the patch panel or enclosure is compatible with snap-in modules and that the fiber type matches your network requirements. Use dust caps when ports are not in use to maintain cleanliness and performance.
