GIRA 448503 Toma de corriente Schuko con tapa abatible, System 55, blanco puro brillante

Protect your indoor sockets from dust and accidental contact with the GIRA 448503 Schuko socket outlet. Its hinged cover closes securely to shield the contacts, while the built-in child protection shutters prevent objects from being inserted into the live terminals. This flush-mounted insert fits standard Gira System 55 frames and covers, making it a reliable choice for safety-conscious homes and offices.

Who is it for

Ideal for households with children, rental properties, and any indoor space where sockets need extra protection against dust, moisture, or tampering. It suits electricians and DIY installers working with Gira System 55 wiring accessories.

Main features

• Schuko (Type F) socket outlet, 1-gang
• Hinged cover (Klappdeckel) for contact protection
• Increased touch protection with child safety shutters
• Flush-mounted (Unterputz) installation
• Screw terminals for conductors up to 2.5 mm²
• Pure white glossy finish (RAL 9010)
• Halogen-free thermoplastic material
• Compatible with Gira System 55 frames and covers

Specifications

• Socket standard: Schuko (Type F)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Colour: Pure White Glossy
• Material: Thermoplastic (PC)
• IP protection class: IP44 (with hinged cover closed)
• Child protection shutters: Yes
• Halogen-free: Yes
• System compatibility: Gira System 55
• Number of sockets: 1
• Cover type: Hinged cover
• RAL colour code: RAL 9010
• Installation depth: 32 mm
• Terminal capacity: up to 2.5 mm² (rigid conductors)
• Suitable for: Indoor use
• Certification: VDE

Tips

Pair this insert with a Gira System 55 frame and cover plate in the same pure white glossy finish for a seamless look. Ensure the installation box has a depth of at least 32 mm. For wet or outdoor areas, combine with an appropriate surface-mounted housing that maintains the IP44 rating.
