GIRA 448527 Toma de corriente Schuko con tapa abatible y campo de rotulación, System 55, blanco puro

In many installations, a standard socket outlet leaves the plug contacts exposed to dust, moisture, and accidental contact. The GIRA 448527 addresses this by combining a Schuko socket with a hinged cover and a labeling field, keeping the outlet protected when not in use while allowing clear identification of circuits.

Who is it for

Electricians and homeowners working with Gira System 55 flush-mounted installations who need a reliable, protected socket outlet with the ability to label individual sockets for better organization.

Main features

• Schuko socket outlet (Type F) with earthing pin
• Hinged cover to protect contacts when not in use
• Integrated labeling field for circuit identification
• Designed for Gira System 55 frames
• Flush-mounted installation
• Rated for 250 V AC and 16 A
• Screw terminals for secure wiring
• Thermoplastic construction in pure white

Specifications

• Socket standard: Schuko (Type F)
• Number of gangs: 1
• Rated voltage: 250 V AC
• Rated current: 16 A
• Connection terminals: screw terminals
• Mounting type: flush-mounted
• System compatibility: Gira System 55
• Material: thermoplastic
• Colour: pure white
• Earthing type: earthing pin (Schutzkontakt)
• Application environment: indoor
• Installation depth: approx. 32 mm

Tips

For use in damp environments, the socket can be upgraded to IP44 protection with an appropriate sealing set (not included). The labeling field allows for easy identification of circuits in multi-socket installations.
