GoodConnections toma de red de pared Cat.6A 2xRJ45 apantallada empotrada entrada de cable vertical blanco señal RAL9003

The GoodConnections Cat.6A Network Wall Outlet (GC-N0020) is a high-performance, shielded flush-mount data socket designed for professional network installations. With two RJ45 ports, it supports 10 Gigabit Ethernet (10GBASE-T) and operates at up to 500 MHz, making it ideal for demanding LAN environments. The vertical cable entry and design-capable frame ensure seamless integration with various switch programs, while the signal white RAL9003 finish provides a clean, modern look.

Advantages

This outlet delivers reliable, high-speed connectivity with robust shielding against electromagnetic interference. Its flush-mount design saves space and maintains a tidy appearance. The LSA termination system simplifies installation, and the gold-plated contacts ensure long-lasting signal integrity. PoE support (up to 4PPoE) allows power delivery to connected devices.

Suitable for

• Professional network cabling in offices, data centers, and residential buildings
• 10GBASE-T networks requiring Cat.6A performance
• Installations where shielded connections are necessary to reduce crosstalk and noise
• Integration with design-oriented switch plate systems

Key specifications

• Product Type: Network Wall Outlet / Data Socket
• Performance Category: Cat. 6A (Class EA)
• Number of Ports: 2
• Connector Type: RJ45
• Shielding: Shielded (FTP/STP compatible)
• Mounting Type: Flush-mount (Unterputz)
• Cable Entry Direction: Vertical
• Colour: Signal White
• RAL Colour Code: RAL 9003
• Data Transfer Rate: Up to 10 Gigabit Ethernet (10GBASE-T)
• Frequency Bandwidth: Up to 500 MHz
• Wiring Standard: TIA/EIA 568A/B
• Termination Type: LSA (Insulation Displacement Connector)
• Contact Material: Gold-plated contacts
• Housing Material: ABS Plastic
• Cable Compatibility: Solid and stranded conductors (AWG 22-24)
• PoE Support: PoE, PoE+, 4PPoE (IEEE 802.3af/at/bt)
• Application: Local Area Networks (LAN)
• Certifications: RoHS, CE

Recommendations

For optimal performance, use with Cat.6A shielded patch cables and compatible faceplates. Ensure proper grounding of the shielding to maximize interference protection.
