Grabador de vídeo en red 4K UHD de 32 canales BCS-L-NVR3202-A-4KE(2)

The BCS-L-NVR3202-A-4KE(2) is a high-performance 32-channel network video recorder (NVR) designed for professional IP surveillance systems. It supports up to 8MP (4K UHD) recording resolution and advanced H.265+ compression to maximize storage efficiency. With 200 Mbps incoming and outgoing bandwidth, this NVR ensures smooth recording and remote access for large-scale installations.

Advantages

Supports 32 IP cameras with 4K UHD resolution; H.265+ compression reduces bandwidth and storage requirements by up to 50%; dual SATA ports support up to 20TB total storage; HDMI 4K output for high-definition local monitoring; ONVIF Profile S/G/T compliant for broad compatibility with third-party cameras.

Suitable for

• Medium to large retail stores, warehouses, and office buildings
• Multi-camera surveillance systems requiring high-resolution recording
• Installations needing long-term storage with expandable HDD capacity

Key specifications

• IP Video Input: 32 Channels
• Max Recording Resolution: 8 Megapixels (4K UHD)
• Video Compression: H.265+, H.265, H.264+, H.264
• Incoming/Outgoing Bandwidth: 200 Mbps each
• HDD Support: 2 SATA ports, up to 10TB each (20TB total)
• Video Outputs: 1x HDMI (up to 4K), 1x VGA (up to 1080p)
• Audio: 1x RCA In / 1x RCA Out
• Alarm: 4 In / 2 Out
• Network: 1x Gigabit Ethernet (RJ-45)
• USB: 1x USB 2.0, 1x USB 3.0
• Power: DC12V/4A, consumption <10W (without HDD)
• Operating Temperature: -10°C to +55°C
• Decoding: 2 channels @ 8MP (30fps) or 8 channels @ 1080P (30fps)
• Mobile App: BCS Manager, BCS Line
• ONVIF: Profile S, G, T

Recommendations

For optimal performance, use with BCS or ONVIF-compatible IP cameras. Install in a well-ventilated area. HDDs are not included; select surveillance-grade drives for 24/7 operation.
