HellermannTyton 435-01652 conector de cable push-in, 3 polos, negro, 0,5-2,5mm², 450V, 24A, sin herramientas, EN 60998

Electrical installations often involve joining multiple conductors quickly and safely, but traditional methods like twist-on wire nuts or terminal strips can be time-consuming and prone to errors. The HellermannTyton 435-01652 push-in wire connector eliminates these hassles with a tool-free design that securely connects up to three solid or stranded wires in seconds. Its transparent housing allows visual confirmation of proper insertion, while the integrated test point enables convenient voltage testing without disconnecting the circuit.

Who is it for

This connector is ideal for electricians, panel builders, and DIY enthusiasts working on junction boxes, lighting installations, and general building wiring. It suits applications where fast, reliable, and maintenance-friendly connections are required, especially in confined spaces where screwdrivers are impractical.

Main features

• Tool-free push-in termination for solid and stranded conductors from 0.5 to 2.5 mm² (20–14 AWG solid, 18–14 AWG stranded).
• Rated for 450 V and 24 A, compliant with EN 60998 safety standard.
• Transparent black housing with test point for easy inspection and voltage testing.
• Compact 3-pole design with a stripping length of 11 mm for quick preparation.
• Durable polycarbonate body (UL94 V-2) and tinned copper contacts for corrosion resistance.
• Operating temperature range from -30 °C to +85 °C, suitable for harsh environments.

Specifications

• Brand: HellermannTyton
• Model: 435-01652
• MPN: 435-01652
• EAN: 4250596413784
• Connector type: Push-in wire connector
• Number of poles: 3
• Colour: Black
• Conductor compatibility (solid): 0.5–2.5 mm² (20–14 AWG)
• Conductor compatibility (stranded): 1.0–2.5 mm² (18–14 AWG)
• Rated voltage: 450 V
• Rated current: 24 A
• Housing material: Polycarbonate (PC)
• Contact material: Tinned copper
• Flammability rating: UL94 V-2
• Operating temperature: -30 °C to +85 °C
• Stripping length: 11 mm
• Connection method: Tool-free push-in
• Safety standard: EN 60998
• Insulation: Fully insulated
• Test point: Yes

Tips

For stranded conductors, ensure wires are fully inserted until they bottom out; a slight tug confirms secure retention. Use the test point with a standard multimeter probe to verify voltage without removing the connector. When working in damp locations, pair with appropriate junction boxes to maintain IP protection.
