HellermannTyton QGDHC5.2-8.0M-PA66W-BK brida con base de fijación, negra, 50 uds. 151-04088

For electricians and panel builders securing cable bundles in outdoor or industrial environments, the HellermannTyton QGDHC mounting base cable tie provides a reliable fastening solution. It accommodates bundle diameters from 5.2 to 8.0 mm and comes in a pack of 50 black ties.

Key specifications

• Material: Polyamide 6.6 (PA66W)
• Colour: Black
• Bundle diameter range: 5.2 - 8.0 mm
• Quantity per pack: 50 pieces
• UV-stabilized and weather-resistant
• Operating temperature: -40 °C to +85 °C
• Flammability rating: UL94 V2
• Halogen-free

Why choose it

The integrated mounting base allows the tie to be screwed or riveted onto a surface, keeping cables fixed in place even under vibration. The PA66W material resists UV radiation and weathering, so it remains strong and flexible over time when used outdoors. Its black colour blends into most equipment and installations.

Ideal use cases

• Securing cable harnesses in control cabinets and switchgear
• Outdoor installations exposed to sunlight and rain
• Automotive and transportation applications where vibration is present
• General industrial fastening of pipes, hoses, and cables

Good to know

The tie is halogen-free and has good resistance to alkalis, oils, greases, and chlorinated solvents. It has low moisture absorption, maintaining its mechanical properties in humid conditions. The UL94 V2 rating indicates limited flame propagation.
